China ATV520CC

Model: China ATV520cc

Product Description:

Engine:518cc liquid cooled, longitudinally mounted single-cylinder four-stroke

Carburation:PGM-FI 36mm

Ignition:Full-transistorized with electronic advance

Starter:Electric

Transmission :Manual foot-shift; 5 speed and reverse

Drive:Direct front and rear driveshafts with TraxLok™ and locking front differential.

Front Suspension:Independent double-wishbone; 185mm travel

Rear Suspension:Swingarm with single shock; 185mm travel

Power Steering: Yes

Front Brakes:190mm dual hydraulic discs

Rear Brake:160mm sealed mechanical drum

Front tyres :25 x 8-12

Rear tyres:25 x 10-12

Fuel Capacity (l):17.7L, incl. 5.9L res.

Bore x Stroke (mm):96.0 x 71.0

Dimensions – Length (mm) :2100

Dimensions – Width (mm) :1200

Dimensions – Height (mm) :1210

Wheelbase (mm) :1270

Seat Height (mm) :870

Ground Clearance (mm):190

Towing Capacity (kg) :384
